30W Semi integrated Solar LED Street Light with Rotation Solar Panel solar garden light 30watt

Short Description:

  • High efficacy 130lm/w.

  • Brief Description: 30W Solar LED Sensor Light
  • Type: Street lights, Garden lights
  • Mounting Height: 4-6 meters
  • Net Weight: 15 kg
  • LED Lumen: 4000-5000LM
  • Applications: gardens, streets, roads, community, parks, parking etc..
  • LED Lifespan: >50000H
  • Warranty: 5years


  • Shipping Port: Shenzhen
  • Description: Semi integrated solar LED Street Light
  • Model: LL-SMSL1-30W
  • Product Detail

    Product Tags

    semi integrated solar street light

    Product structure

    The solar light with streamlined design is manufactured with an exclusive private mold and made of aluminum die casting housing.

    30W Solar led street light

    1. Solar panel 2. Microwave/PIR sensor 3.MPPT controller 4. LED chipset 5. Lithium battery 6. Horizontal bracket 7. Vertical bracket

    Function characteristic

    1) Solar panel coulbe be rotated 360º horizontally and 240º vertically, which could increase the photoelectronical vonversion maximum in different areas.

    30W Solar led street light rotate

    2) The integrated optical lens offers excellent light transmittance and durable to resist damage.

    Solar Lights Outdoor chip

    3) First class LED chipset. The advanced lighting technology brings a higher luninous intensity, lower thermal resistance, longer lifespan and a greater luminaire stability.

    20 W Led Solar Street Light chip beam angle

    4) Patent MPPT controller developed b y our RD team. Maxium power charging.

    20 W Led Solar Street Light MPPT

    5) Powerful lithium battery module package, lower self discharge rate, longer lifespan, strong depth of discharging, wider working temperature and environment protecting.

    20 W Led Solar Street Light battery

    6) Microwave/PIR sensor

    Using advanced Microwave/PIR sensor technology, more sensitive and optimize brightness automatically. Max sensing distance is 12meters. The build-in Microwave/PIR sensor could automatically regulate brightness by identify moving object around, increase brightness when object approaches and decrease after object leaves about 20-30s(can be customized). The function of lighting intensity can preserve solar energy effectively.

    30W Solar led street light PIR sensor

    7) Mobile APP

    30W Solar led street light APP

    Specification

    Model NO.  LL-SMSL1-30W
    LED Chipset  3535 LED
    Chipset Q'ty  42PCS
    Light Efficiency  130LM/W±10LM
    Lumen  3500-4500LM
    Color Temperature  3000K-6500K
    CRI >70
    LED Lifespan 50000H
    Electrical characteristic Rated Power 30W
    Solar Panel Power 18V/60W/mono156
    Lithium Battery 12V 264WH
    Charge Time 6-8H
    Discharging Time > 36H
    Working Temparature  -30℃~+60℃
    Switch Threshold 15LUX
    Max sensing Distance ≦12M
    Mechanical Specification Light body size 640*260*250mm
    Solar Panel Size 780*513*30mm
    Net Weight 15 kg
    Mounting Height 4-6 M
    Pole Installation Distance 10-15 M
    Packing Information Q'ty/carton 1 set / 2 cartons
    Carton Size(Lamp) 690*330*320mm
    Carton Size(Solar panel) 825*565*75mm
    Gross Weight 17.8 kg

    Size:

    Solar Led Street Lights SIZE

    Unit: mm

    Application:

    Semi-integrated solar led street light is used for Courtyard, Garden, Park, Street, Roadway, pathway, Parking Lot, Private road, Sidewalk, Public square, plaza, Campus, Farm & Ranch, Perimeter Security, Wildlife area, Remote Area, Military Base, and so on.

    Solar Led Street Lights application
