200W 2 in 1 Solar LED Street Light

Short Description:

  • High efficacy 130-150lm/w.

  • Brief Description: 200W Solar LED Sensor Light
  • Type: Street lights, Garden lights
  • Mounting Height: 11-14 meters
  • Net Weight: 26.5 KG
  • LED Lumen: 26000-30000LM
  • Applications: gardens, streets, roads, community, parks, parking etc..
  • LED Lifespan: >50000H
  • Warranty: 2years


  • Shipping Port: Shenzhen
  • Description: Semi integrated solar LED Street Light
  • Model: LL-SMSL5-200W
  • Product Detail

    Product Tags

    Features:

    1. Based on the classic semi-integrated solar street light, this new product is a creative lighting fixture with features of elegant exterior design, die-casting aluminum housing and customized solar panel and functions of time control, light control, human infrared sensing and Bluetooth APP control.
    2. The direction adjustable solar panel maximizes the solar cell charging efficiency.
    3. It can be matched with AC adaptor and used as a LED street light supplied by commercial electricity with its special controller.
    4. With PHILIPS3030, higher brightness and less energy consumption.

    Function characteristic
    1) Light control: the street light can turn on/off automatically by checking whether it is dark /bright according to the brightness of the currnt environment.
    Light control
    2) Mobile phone Bluetooth APP control: Check the current state of street lights on the mobile phone in real time and reset various parameters of the street light.

    APP3) Time control: Set different brightness of different period of time.
    time control

    4) Angle adjustable: The angle of solar panel and lamp holder can be adjustable. The solar panel can be adjusted horizontally 360 degree and vertically 105 degree. The maximum adjustable angle is 225 degree.

    Angle adjustable

    Main components

    ComponentsComponents 3

    Specification

    Model NO. LL-SMSL5-200W
    LED Chipset PHILIPS3030
    Chipset Q'ty 240PCS
    Light Efficiency 130LM-150LM
    Lumen 26000-30000LM
    Color Temperature 2800K-6500K
    CRI >70
    LED Lifespan 50000H
    Electrical characteristic Rated Power 200W
    Solar Panel Power 30V/165W
    Lithium Battery 22.2V / 1500.7WH
    Charge Time 7 Hours with summer's sunshine
    Discharging Time 3-10 rainy days, 12hours per night,Or you can set your lighting time via Mobile APP
    Working Temparature  -30℃~+60℃
    Switch Threshold 15LUX
    Max sensing Distance ≦12M
    Mechanical Specification Product Size 700x315x90MM
    Solar Panel Size 1400X665MM
    Net Weight 26.5KG
    Mounting Height 11-14 M
    Pole Installation Distance 40-45m for one-side road lighting; 60-70m for both-side road lighting.
    Packing Information Q'ty/carton 1PCS/CTN
    Carton Size(Solar panel) 1445x725x210MM
    Gross Weight 29KG

    Application:

    Semi-integrated solar led street light is used for Courtyard, Garden, Park, Street, Roadway, pathway, Parking Lot, Private road, Sidewalk, Public square, plaza, Campus, Farm & Ranch, Perimeter Security, Wildlife area, Remote Area, Military Base, and so on.
    application
