20W 30W LED Linear Downlight DL76 1M 1.2M Downlight LED COB Linear Grille Spot Light for Indoor Lighting Fixture

Short Description:

  • LED linear light.

  • UGR<19.
  • High efficiency & energy saving.
  • No UV & IR . It won’t distribute ray radiation.
  • Eco-friendly, No Hg & Xe, or other harmful element.
  • Recyclable, also it won’t generate EMI.
  • 5 years warranty


  • Shipping Port: Shenzhen
  • Description: LED Linear Spot Light
  • Model: LL-DL76-10-2C / LL-DL76-12-2C / LL-DL76-15-2C
  • Product Detail

    Product Tags

    Features:

    1. Original CREE chipset.
    2. It takes high brightness led lamp.
    3. Use constant current driver. No flicker, no glare, very soft and even light.
    4. High light efficiency, low power consumption, save much energy.
    5. Lift time could reach 50,000 hrs.
    6. Easily embedded installation.

    Specification

    Model LL-DL76-10-2C LL-DL76-12-3C LL-DL76-15-4C
    Power(±10%) 20W 30W 40W
    Input(Frequency) AC 220-240V(50/60Hz)
    Product Dimension W35*H75.6*L1000mm W35*H75.6*L1200mm W35*H75.6*L1500mm
    Lumen 1300lm 1950lm 2600lm
    Luminous Efficacy 65lm/w 65lm/w 65lm/w
    PF >0.9
    LED Type&Q‘ty 10pcs CREE XTE 15pcs CREE XTE 20pcs CREE XTE
    CCT(K) 3000K / 4000K / 6000K
    CIR(Ra) ≥80
    Beam angle 10° 24° 36° 48°
    Working Temperature -30℃~45℃
    Storage Temperature -40℃~70℃
    LED Driver OSRAM X-power / Lifud
    Life span of Light Source ≧50000 H(Ta=30°C@L70)
    IP Grade IP40
    Body Materials Aluminum Alloy
    Certificate CE, Rohs


    Size:

    LED LINEAR SPOT LIGHT SIZE

    Unit: mm

    Application:

    LED Linear Spot Light is widely used for places of high requirement of lighting, such as library, shopping mall, hotel, museum, gallery, experience center, commercial building, etc.

    LED LINEAR SPOT LIGHT APPLICATION
