Factory price 30W 40W LED linear light for office using, aluminium lighting fixture Pendant Luminaires DL76 1.0M 1.2M

Short Description:

  • LED linear light.

  • UGR<19.
  • High efficiency & energy saving.
  • No UV & IR . It won’t distribute ray radiation.
  • Eco-friendly, No Hg & Xe, or other harmful element.
  • Recyclable, also it won’t generate EMI.
  • 5 years warranty


  • Shipping Port: Shenzhen
  • Description: LED Linear Spot Light
  • Model: LL-DL76-10-2F / LL-DL76-12-2F / LL-DL76-15-2F
  • Product Detail

    Product Tags

    Features:

    1. Original CREE+Osram chipset.
    2. It takes high brightness led lamp.
    3. Use constant current driver. No flicker, no glare, very soft and even light.
    4. High light efficiency, low power consumption, save much energy.
    5. Lift time could reach 50,000 hrs.
    6. Easily embedded installation.

    Specification

    Model LL-DL76-10-2F LL-DL76-12-2F LL-DL76-15-2F
    Power(±10%) 20/10W 20/20W 20/30W
    Input(Frequency) AC 220-240V(50/60Hz)
    Product Dimension W35*H75.6*L1000mm W35*H75.6*L1200mm W35*H75.6*L1500mm
    Lumen 1300/650lm 1300lm 1300/1950lm
    Luminous Efficacy 65lm/w 65lm/w 65lm/w
    PF >0.9
    LED Type&Q‘ty 10pcs CREE XTE 20W + 70pcs SMD2835 10W 10pcs CREE XTE 20W + 98pcs SMD2835 20W 10pcs CREE XTE 20W + 112pcs SMD2835 30W
    CCT(K) 3000K / 4000K / 6000K
    CIR(Ra) ≥80
    Beam angle 10° 24° 36° 48° +100°
    Working Temperature -30℃~45℃
    Storage Temperature -40℃~70℃
    LED Driver OSRAM X-power / Lifud
    Life span of Light Source ≧50000 H(Ta=30°C@L70)
    IP Grade IP40
    Body Materials Aluminum Alloy + PMMA
    Certificate CE, Rohs


    Size:

    LED LINEAR SPOT LIGHT SIZE

    Unit: mm

    Application:

    LED Linear Spot Light is widely used for places of high requirement of lighting, such as library, shopping mall, hotel, museum, gallery, experience center, commercial building, etc.

    LED LINEAR SPOT LIGHT APPLICATION
