100W- 1000W LED Flood light
Description:
LOWCLED Module LED floodlight 4M series is a new type of LED lighting source. Compared with traditional floodlights, products developed on the basis of traditional floodlights have high thermal conductivity, low light decay, pure light, and no ghosting. Energy saving, environmental protection, long service life, etc.
Specification:
| Model | LL-FLX-100W-4M | LL-FLX-200W-4M | LL-FLX-300W-4M | LL-FLX-400W-4M | LL-FLX-500W-4M | LL-FLX-600W-4M | LL-FLX-800W-4M | LL-FLX-1000W-4M |
| Wattage | 100W | 200W | 300W | 400W | 500W | 600W | 800W | 1000W |
| Input Voltage | 100-277V/277-480V/100-347V,50 / 60 Hz | |||||||
| Luminous Flux | 13000lm-16000lm | 26000lm-32000lm | 39000lm-48000lm | 52000lm-64000lm | 65000lm-80000lm | 78000lm-96000lm | 104000lm-128000lm | 130000lm-160000lm |
| Color Temperature | 3000K/ 4000K/ 5000K/5700K/ 6500K | |||||||
| Beam Angle | 70*140º/ 90º/60º/30º | |||||||
| CRI | Ra70 (Ra80 or Ra90 optional) | |||||||
| PF | ≥0.95 | |||||||
| Operation Temperature | -40°C to + 50°C (-40°F to 122°F) | |||||||
| Net Weigh(kg/lbs) | 2.2 / 4.9 | 2.9 / 6.4 | 3.9 / 8.6 | 5.3 / 11.7 | 5.9 / 13.0 | 7.8 / 17.2 | 10.6 / 23.4 | 11.8 / 26.0 |
| GrossWeight (kg/lbs) | 2.5 / 5.5 | 3.5 / 7.7 | 4.5 / 9.9 | 6.0 / 13.2 | 6.7 / 14.8 | 9.0 / 19.8 | 12.0 / 26.5 | 13.4 / 29.5 |
| Size Of Box(mm/in) | 435*215*110 / 17.1*8.5*4.3 | 435*350* 110 / 17.1*13.8*4.3 | 435*450*110 / 17.1*17.7*4.3 | 435*560*110 / 17.1*22.0*4.3 | 435*665*110 / 17.1*26.2*4.3 | 435*770*110 / 17.1*30.3*4.3 | 830*560* 110 / 32.7*22.0*4.3 | 830*665* 110 / 32.7*26.2* 4.3 |
Size:
Application:
Lowcled led flood light is widely used at Football Stadium,Gymnasium, Harbor, Tunnel, Architectural, Square. Ideal for illuminating building facade, large trees, walls, industrial yard, recreational area, and other general purpose area application.
